PN: CFT515004 - Centerforce II Clutch Pressure Plate And Disc Set

The Centerforce(R) II Clutch Series utilizes a full facing disc with premium friction material and a pressure plate with centrifugal weights (where applicable). Furthermore, static clamp load is increased via our patented machining processes; this combination allows superb holding power and maximum clutch life, making this clutch ideal for selected street/strip, off-road and towing applications. Pressure plate and disc sold separately on some applications. The Torque Figures for Centerforce II Pressure Plates are based and calculated in conjunction with a Centerforce I & II Clutch Disc.

• 8-7/8" Diameter;

Attributes:

• GTIN: 00788442015560
• Brand Name: Centerforce
• Clutch Disc Diameter: 8-7/8
• Clutch Disc Diameter: 225
• Counterweight Assist5: No
• Disc Material3: Organic
• Disc Type Sprung Solid2: Sprung
• Disc Type6: Full face
• Input Shaft Diameter1: 1
• Input Spline Quantity2: 23M
• Material4: Cast Iron Pressure Plate / Organic Friction
• Torque Capacity: 330

Extended Information:

• Country of Origin: Mexico
• Emissions : CARB Eligible
• Life Cycle Status: Discontinued

Packing Information:

• Quantity of Each: 1
• Package UOM: EA
• Dimension: 14 x 14 x 4 inches
• Weight: 14.49 lb
